According to EN12209, DIN18251-1
Edge pull, forend and strike plates made of SUS304
Prepare for euro cylinder
Used for pocket door
| Backset | 55mm |
|---|---|
| Forend Width | 20/24 mm |
| Forend Type | Round head / Square head |
| Finish | SSS/AB/AC/Gold PVD/BL |
Technical Information:
Backset:55mm
Forend: 235mm*20mm*3mm; Round / Square Head
Hook: zinc , 50,000 cycles test
Edge pull: SUS 304
Lockcase: Steel galvanised with blue coating, SECC, thickness 1.5mm
Striking plate: SUS304, thickness 1.5mm
Accessories: plastic box (PE material) & fixing screws (for wooden door or steel door optional)
Package: brown inner box and brown carton box (colour box available)
