According to EN12209, DIN18251-1
Deadbolt,forend and strike plates made of SUS304
Prepared for profile cylinders
With key action, deadbolt 2-turn
Backset | 35/55mm |
---|---|
Forend Width | 20/22/23/24 mm |
Forend Type | Round head / Square head |
Finish | SSS/AB/AC/Gold PVD/BL |
Technical Information:
Backset: 35/55mm
Forend: 138mm*20/22/23/24mm*3mm; Round / Square Head
Deadbolt: SUS 304, 2-turn (20mm), 50,000 cycles test
Lockcase: Steel galvanized with blue coating, SECC, thickness 1.5mm
Striking plate: SUS304, thickness 1.5mm
Accessories: plastic box (PE material) & fixing screws (for wooden door or steel door optional)
Package: brown inner box and brown carton box (colour box available)
Features:
Successfully tested to EN12209
Classification Code: 3 X 8 1 0 G 3 B C 0 0
