According to EN12209, DIN18251-1
Forend and strike plates made of SUS304
Prepared for profile cylinders
With key action, deadbolt 2-turn
| C-T-C Distance | 72 mm |
|---|---|
| Backset | 40/45/50/55/60/65/70/80/100 mm |
| Forend Width | 20/22/23/24 mm |
| Forend Type | Round head / Square head |
| Finish | SSS/AB/AC/Gold PVD/BL |
Technical Information:
C-T-C Distance:72mm
Backset:40/45/50/55/60/65/70/80/100mm
Forend: 235mm*20/22/23/24mm*3mm; Round / Square Head
Deadbolt: SUS 304, 2-turn (20mm), 50,000 cycles test
Lockcase: Steel galvanised with blue coating, SECC, thickness 1.5mm
Striking plate: SUS304, thickness 1.5mm
Accessories: plastic box (PE material) & fixing screws (for wooden door or steel door optional)
Package: brown inner box and brown carton box (colour box available)
Features:
Successfully tested to EN12209
Classification Code: 3 X 8 1 0 G 3 B C 0 0
Dimension according to DIN18251-1
