Technical Information:
C-T-C Distance:72/85mm
Backset:50/55/60mm
Forend: 196mm*18mm*3mm; Round Head
Magnetic bolt: 200,000 cycles test ( Nylon with fiber, gray color, the strong magnet inside.
Lockcase: Steel galvanized with blue coating, SECC, thickness 1.5mm
Follower: 8*8mm,
| C-T-C Distance | 72/85 mm |
|---|---|
| Backset | 50/55/60mm |
| Forend Width | 18 mm |
| Forend Type | Round head |
| Finish | SN/AB/AC/Gold PVD/BL |
Magnetic profile locks Key Benefits:
Silent Operation: These locks utilize strong magnets to automatically retract the latch upon opening, resulting in a near-silent closing action. This feature is particularly advantageous in environments where noise reduction is desired.
Aesthetic Appeal: The flush design of magnetic sashlocks contributes to a sleek, minimalist appearance, enhancing the overall aesthetic of modern interiors.
Enhanced Security: Many magnetic sashlocks are compatible with euro cylinders, allowing for key-operated locking mechanisms that provide robust security. The chamfered bolt design and hardened steel pins offer resistance against common attack methods such as sawing and picking.
Reversible Handing: The symmetrical latch design enables these locks to be used on both left and right-handed doors without the need for adjustments, simplifying installation and inventory management.
Durability: Constructed from high-quality materials like steel and available in finishes such as polished chrome and matt black, these locks are designed for longevity and resistance to wear.
