According to EN12209, DIN18251-1
Latchbolt, forend and strike plates made of SUS304
Suitable for sprung and most unsprung lever handles
Prepared for profile cylinders
With key action, deadbolt 2-turn
Magnetic latch, no friction noise
| C-T-C Distance | 85 mm |
|---|---|
| Backset | 45//50/60mm |
| Forend Width | 20/22/23/24 mm |
| Forend Type | Round head / Square head |
| Finish | SSS/AB/AC/Gold PVD/BL |
Technical Information:
C-T-C Distance:85mm
Backset:45/50/60mm
Forend: 240mm*20/22/23/24mm*3mm; Round / Square Head
Latch: magnet latch, 200,000 cycles test
Deadbolt: SUS 304, 2-turn (20mm), 50,000 cycles test
Lockcase: Steel galvanized with blue coating, SECC, thickness 1.5mm
Follower: 8*8mm, SUS304
Striking plate: SUS304, thickness 3.0mm
Accessories: fixing screws (for the wooden door)
Package: brown inner box and brown carton box (colour box available)
Features:
Dimension according to DIN18251-1
